GPS GSM GPRS Car Speed Controller Ethiopia Standard Vehicle GPS
Speed Limiter
Vehicle speed limiter CA100F is a intelligent terminal equipment
which can realize precise speed limiting for vehicles. It is not
only a speed limiter but also a GPS Tracker.
The rate of change of speed shall not exceed 0.5 mls2 when measured
on a period greater
The stabilized speed conditions specified in clause 3.2.6 shall be
attained within 10 s of first reaching of the set speed Vset.
Stabilized Speed (Fig.1) Vstab is the average speed calculated for
a minimum time interval of 20s beginning 10s after first reaching
Vset.
1.Product features:
(1). Function: limiting speed.
(2). Speed range: 10 to 120km/h.
(3) .Speed limit deviation: ± 1km/h.
(4). The operating voltage range of the products: 9-36V.
(5). Application temperature:-20℃ to 70℃.
(6). Rated power consumption 2W.
(7). Apply to all kind of vehicle
2.Technical parameters
| Content | Specs. |
| Dim. | 117*65*31 (mm) |
| Weight | 200g |
| Network | GSM/GPRS/GPS |
| CPU | STM32F105RBT6 |
| Power IC | TD1509-ADJ |
| Anti-jamming | Strengthened Anti-jamming |
| GPS sensitivity | -159dBm |
| GPS accuracy | 5 m |
| Time To First Fix | Reacquisition 0.1s |
| Cold status 45s |
| Warm status 35s |
| Hot status 1s |
| Work Voltage | DC 9V－36V |
| Battery | 3.7V / 1000mAh Li-ion battery (Customizable) |
| Standby work current | < 40mA |
The vehicle speed limiter can be installed in the car, bus, school
bus, truck, garbage truck,oil tank truck,ect!
GPS GSM GPRS Car Speed Controller Ethiopia Standard Vehicle GPS
Speed Limiter
The install steps:
1. Find the vehicle accelerator pedal line harness at first, then
find the two signal lines from the six lines with multi-meter test.
2. Cut the two signal lines, and then connect <10brown
line+9yellow line> and <4blue line+3white line> to the
signal lines respectively.
3. Find the speed pulse signal line of the car, connect to the 9
gray line of the GPS speed limiter, connect the speed pulse line,
and the speed limit delay time is within 1 second.
GPS GSM GPRS Car Speed Controller Ethiopia Standard Vehicle GPS
Speed Limiter
About platform
1. Load the GPS platform: www.ytwl-gps.com
User:xxxx password:123456
Note: xxxx is the platform account, need to contact with
salesman to get this account name and password
For APP, search GPS SPEED LIMITER in google store or
download from this QR:
FAQ
1. Q: Why can we believe you?
A: Our products have passed the strict certification of CE, FCC,
RoHS. In addition,we have 12 years professional R&D team,and
established long-term partnerships with fortune 100 companies.
2. Q: What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown
cartons. If you have legally registered patent, we can pack the
goods in your branded boxes after getting your authorization
letters.
3. Q: Is it possible to buy a sample to test?
A: Yes. You can buy a sample to test.You do not have to worry about
the quality of products,we have exported to 100 countries all over
the world.
4. Q: How to make the order?
A: You have many ways to contact us to make the order.Email:
peter@gpstrackinglocator.com
5. Q: Do you accept OEM & ODM orders?
A: Yes,We are a professional factory that can provide professional
OEM & ODM services.
