Speed Limit 30 Road Speed Ethiopia Standard CE Gps Speed Limiter

Vehicle speed limiters & GPS trackers

Ethiopia has provisionally agreed new rules that state speed limiters will become mandatory for all vehicles sold throughout the country.

Road Speed Limiters were developed to improve safety and the environment by controlling the speed of vehicles, thus reducing serious accidents and pollution. The basic function of the system is to limit the maximum speed of a vehicle to a pre-set level without affecting any of the performance of the vehicle.

Whether you operate a small or large fleet, you can be confident that we offer the speed limiters Approved by Ethiopian Transport Authority at the reasonable prices with a dedicated customer service.

1. Product Brief:

Vehicle speed limiter CA100F is an intelligent terminal equipment which can realize precise speed limiting for vehicles. It is not only a speed limiter but also a GPS Tracker. Speed control precision is very high and the performance is reliable. It will not affect the big throttle start nor the power torque, stable and reliable. It only limits the maximum speed and the vehicle will not stall during speed limiting, and ensure the throttle pedal

1.1 Product Function:

2. Application Field:

1.Vehicle Commanding and Dispatching System;
2.Heavy Construction Vehicles Tracking Device;
3.Dangerous goods transportation;

Main Features

Vehicle Speed limiter with GPS Car Tracking System are designed to reduce accidents. They limit the maximum speed of a vehicle by restricting the fuel supply to the engine; Hence Speed Limiter improves road safety with increased fuel efficiency and reduced repair cost.

Speed Limit 30 Road Speed Ethiopia Standard CE Gps Speed Limiter

3. Technical Parameter:

Speed Limit 30 Road Speed Ethiopia Standard CE Gps Speed Limiter

3. Including

Analysis of the content of tcp reply:

(TP121.201.110.106P7000DD000019171223244F0000S0014R0000ON30OFF60VJun 12 2020A:CMNET,p450,s80,c15, 0.360V, 0.720V,12.43V,a0,G00,-59 dbm)

TP121.201.110.106 P7000: IP and port

DD000019171223244: device ID number

F0000S0014: upload data fail 0 times, successful 14 times

R0000: memory data is 0

ON30OFF60: interval of acc on is 30 seconds, and acc off is 60 seconds

VJun 12 2020: firmware of the devices is JUN 12 2020

A:CMNET: the APN is CMNET

p450: Pulse coefficient is 450 (If the pulse coefficient is larger, the speed will be smaller)

s80: speed limiter max =80km/h

c15: For mechanical throttle, the time to disconnect the fuel line is 15 seconds

0.360V, 0.720V: Two throttle voltage values for electronic throttle vehicles

12.43V: vehicle voltage values

a0: a0 is acc off, a1 is acc on

G00: G00 means GPS not fixed, G10 means 10 satellites found

-59 dbm: GSM signal

4. Installation:

4.1 How to set the speed limit value

After GPS SPEED LIMITER is installed completely, start the vehicle first. When the vehicle is idling, send a text message “STARTIDLE*123456”, the device will automatically learn the idle voltage, and then return the learned idle voltage value to the mobile phone---- this is very important!

Then use the text message "SPEED*123456*40" to set the speed limit value, first test it with GPS speed, and the speed limit function is normal.

3.4.2 How to calibrate the pulse coefficient

You can find the original car speed pulse line to be connected with the device’s pulse line. Then you can make the car run at a constant speed of 30km/h, then press the button twice to calibrate the current pulse coefficient.

Please be noted with: same vehicles have the same pulse coefficient

The default pulse coefficient is 450.

If you already know the pulse coefficient of the vehicle, you can set it directly by SMS.

PULSE*123456*26 (Note: this command sets the pulse coefficient to 26)

And you can set the speed limit value from platform when device is online, as following picture:

1) Product Accessory:

①　Power wire

②　Executor wire

③　Extension wire

④　Speaker

⑤　GPS Antenna

⑥　GSM Antenna

⑦　SIM Card Slot

⑧　User Manual

5. ADD GPS device to the platform

About platform

1. Load the GPS platform: www.gps-go.com

User:xxxx password:123456

Note: xxxx is the platform account, need to contact with salesman to get this account name and password

For APP, search gps-go in google store or download from this QR:

2. The platform functions and report

3. Track : you can see the real-time location of the vehicle

Technical specifications for Goods

· Speed Limiter Device with Integrated GPS: As per standard set by Ethiopian Standard Agency Standard Road Vehicle-GPS integrated Speed limiter Devices Requirements

· To provide Warranty for two years for any problem that arise due to the device internal problem but this doesn’t include for damage due to external force , extreme heat, fire or voltage of electricity or when the devise is opened by any other person other than the company’s technician

· Speed Limit Equipment competency Verification Certificate is approved by the Ethiopian Road Authority to supply and install Speed Limiter with integrated GPS system.

· Committed to comply with Human rights and labour issues (e.g. fundamental principles and rights at work, occupational health and safety, fairly traded goods, etc)
