YTWL_CA100F Road Ethiopia GPS Integrated Speed Limiter - For
Ethiopia
Supply and Installation of Speed Limiter with the integrated GPS
system on 200 units of vehicles
Reference: ITB/2020/13893
Beneficiary Country: Ethiopia
Registration level: Basic
Ethiopia has provisionally agreed on new rules that state speed
limiters will become mandatory for all vehicles sold throughout the
country.
Road Speed Limiters were developed to improve safety and the
environment by controlling the speed of vehicles, thus reducing
serious accidents and pollution. The basic function of the system
is to limit the maximum speed of a vehicle to a pre-set level
without affecting any of the performance of the vehicle.
Technical Parameter:
| Content | Specs. |
| Dim. | 117*92*31 (mm) |
| Weight | 280g |
| Network | GSM/GPRS/GPS |
| Band | 850/900/1800/1900MHz |
| GPS chip | U-blox |
| GSM/GPRS Module | SIM800C |
| Bluetooth Module | BT360I |
| CPU | STM32F105RBT6 |
| Power IC | TD1509-ADJ |
| Anti-jamming | Strengthened Anti-jamming |
| GPS sensitivity | -159dBm |
| GPS accuracy | 5 m |
| Time To First Fix | Reacquisition 0.1s Cold status 45s Warm status 35s Hot status 1s |
| Work Voltage | DC 9V－36V |
| Battery | Rechargeable 3.7V / 1000mAh Li-ion battery (Customizable) |
| Standby work current | < 40mA |
| Storage Temp. | -40°C to +85°C |
| Operation Temp. | -20°C to +70°C |
| Humidity | 5%--95% non-condensing |
YTWL_CA100F Road Ethiopia GPS Integrated Speed Limiter - For
Ethiopia
2. Application Field:
Fixed Speed Control
The customized fixed maximum top speed limit increases the safety
and fuel economy of your fleet.
Reverse Speed Control
Limits a vehicle's top speed in reverse. Limiting reverse top speed
increases safety during a statistically high-risk category of
operation.
Acceleration Control
Controls the rate at which the vehicle is able to accelerate.
Inhibiting aggressive driving behaviors, increasing safety, and
greatly improving fuel economy.
Upgradeable to ISA
Upgrade your VMS from fixed top speed limiting to variable top
speed limiting at any time with our optional SpeedIQ kit. The
upgrade offers even override Mode
Configurable overrides by a variety of input methods. This
capability is especially useful for Emergency Services and other
who require access to full speed and acceleration at times.
YTWL_CA100F Road Ethiopia GPS Integrated Speed Limiter - For
Ethiopia
3. Including
Analysis of the content of TCP reply:
(TP121.201.110.106P7000DD000019171223244F0000S0014R0000ON30OFF60VJun 12 2020A:CMNET,p450,s80,c15, 0.360V, 0.720V,12.43V,a0,G00,-59 dbm)
TP121.201.110.106 P7000: IP and port
DD000019171223244: device ID number
F0000S0014: upload data fail 0 times, successful 14 times
R0000: memory data is 0
ON30OFF60: interval of acc on is 30 seconds, and acc off is 60
seconds
VJun 12 2020: firmware of the devices is JUN 12 2020
A:CMNET: the APN is CMNET
p450: Pulse coefficient is 450 (If the pulse coefficient is larger,
the speed will be smaller)
s80: speed limiter max =80km/h
c15: For mechanical throttle, the time to disconnect the fuel line
is 15 seconds
0.360V, 0.720V: Two throttle voltage values for electronic throttle
vehicles
12.43V: vehicle voltage values
a0: a0 is acc off, a1 is acc on
G00: G00 means GPS not fixed, G10 means 10 satellites found
-59 dbm: GSM signal
4. Installation:
1) Product Accessory:
① Power wire
② Executor wire
③ Extension wire
④ Speaker
⑤ GPS Antenna
⑥ GSM Antenna
⑦ SIM Card Slot
⑧ User Manual
The following lines are indispensable in the installation:
6: Brown line
8: Orange line, the line of the buzzer
9: Grayline, pick up the pulse line of the original car, connect
the pulse line speed limiter, the speed limit function will not
have too much delay, use GPS signal speed limit, there will be a
delay of about 2 seconds
10: ACC line
11: Power ground
12: Positive power supply
5. ADD GPS device to the platform
About platform
1. Load the GPS platform: www.gps-go.com
User:XXXX password:123456
Note: XXXX is the platform account, need to contact a salesman to
get this account name and password
For APP, search gps-go in google store or download from this QR:
2. The platform functions and report
3. Track: you can see the real-time location of the vehicle
How can I buy it?
We accept T/T, Western Union, and Paypal after payment cleared.
then we will send goods to you.
