YTWL_CA100 Ethiopian Road GPS Speed Limiter For New Car/Vehicle
Supply and Installation of Speed Limiter with the integrated GPS
system on 200 units of vehicles
Reference: ITB/2020/13893
Beneficiary Country: Ethiopia
Registration level: Basic
Ethiopia has provisionally agreed on new rules that state speed
limiters will become mandatory for all vehicles sold throughout the
country.
Technical Parameter:
| Content | Specs. |
| Dim. | 117*92*31 (mm) |
| Weight | 280g |
| Network | GSM/GPRS/GPS |
| Band | 850/900/1800/1900MHz |
| GPS chip | U-Blox |
| GSM/GPRS Module | SIM800C |
| Bluetooth Module | BT360I |
| CPU | STM32F105RBT6 |
| Power IC | TD1509-ADJ |
| Anti-jamming | Strengthened Anti-jamming |
| GPS sensitivity | -159dBm |
| GPS accuracy | 5 m |
| Time To First Fix | Reacquisition 0.1s Cold status 45s Warm status 35s Hot status 1s |
| Work Voltage | DC 9V－36V |
| Battery | Rechargeable 3.7V / 1000mAh Li-ion battery (Customizable) |
| Standby work current | < 40mA |
| Storage Temp. | -40°C to +85°C |
| Operation Temp. | -20°C to +70°C |
| Humidity | 5%--95% non-condensing |
YTWL_CA100 Ethiopian Road GPS Speed Limiter For New Car/Vehicle
Main Function:
- Real-time GPS tracking
- Geo-fences
- ACC status detection
- Over speed alarm
- Power cut alarm
- Low voltage alarm
- Abnormal GPS antenna alarm
- SOS alarm (SOS button)
- Cut fuel and power, Speed limit (Relay, Support mechanical
valves)
- Audio monitoring (MIC or Intercom)
- Fuel monitoring (Fuel sensor)
- Temperature monitoring (Temperature sensor)
- Print vehicle trip data (Printer)
1. speed limit, 5--225km/h.
2. tamper Protection Mode(disconnect signal wire / power wire,into
limp model).
3. speed record onboard and off-board ( Date & Time, Speed, Highest
speed, Violation).
4. limiter device can resistant to reverse polarity connections.
5. over speed alarm & pre-warn alarm. this warning occurs at 5%
prior to the set speed and continues buzzing once the set speed is achieved/exceeded.
6. real-time tracking through web tracking platform and cell phone
app.
7. limiter device uploads the data at not more than 10seconds
intervals.
8. limiter device can store the data in a non-erasable memory for
at least 72 hours even if the power supply is disconnected.9. portable printing is supported, can print out 1hour / highest
speed/violation record.
10. limiter device can work with Valve Speed Sensor Booster
YTWL_CA100 Ethiopian Road GPS Speed Limiter For New Car/Vehicle
Product Accessories:
① Power wire
② Executor wire
③ Buzzer
④ GPS Antenna
⑤ GSM Antenna
⑥ SIM Card Slot
⑦ Bluetooth printer ( Optional )
⑧ Bluetooth antenna
Q&A about GPS Speed Limiter for Ethiopia:
0. Is your GPS Speed Limiter well approved, testified, and
recognized by the Ethiopian market?
Yes, as one of the very first several companies who invented GPS
Speed Limiters for the Ethiopia market according to the standard of
the Ethiopian government our GPS Speed Limiters have been well
approved, testified, and recognized by the Ethiopia market. And we
have been exporting quite a number of GPS Speed Limiters to
Ethiopia every month.
2. What mechanism will the device use to limit the speed of
electronic throttle vehicles and the additional device it uses?
Our speed limiter is an electronic type that works with electronic
throttle vehicles without requiring additional accessories.
