    200mA Electronic Engine Governor Speed Limiting Device Real Time Online Tracking

    Ask Lasest Price
    Brand Name : cartrack
    Model Number : CA100F
    Certification : CE/ROHS/FCC/SGS
    Price : negotiation
    Payment Terms : T/T or western Union or paypal
    Supply Ability : 100,000pcs per month
    Delivery Time : 1-10 working days after received your payment
    • Product Details
    • Company Profile

    200mA Electronic Engine Governor Speed Limiting Device Real Time Online Tracking


    Ethiopia Standard Speed Limiting Device Speed Limiter Real-time Online Tracking​


    1 Product Specifications


    ColorBlackApplicationfree android and IOS app
    Input Fuse5ACPUTI:MSP430F5419(100MHz)
    BatteryLithium battery :400mA( working time is about 3.5 hours)Warranty2 years
    Item NameTop selling shineFunctioncamera gps fleet tracker
    Working TemperatureAnna ShiMOQ10 Pieces
    GSM ModuleGSM Module:SIM5320
    Band:850/900/1800/1900/2100MHz,
    Tally with: GSM phase 2/2+
    -Class 4 (2W @ 850/900MHz)
    -Class 1 (1W @ 1800/1900MHz)
    Max RF Output: 33.0dBm±2dBm
    Dynamic Input Range: -15 ~ -102dBm
    Receiving delicacy: Class RBER≤2%(-102dBm)
    Frequency Stability: > 2.5ppm
    Max Frequency Deviation: ±0.1ppm
    RMS Deviation: ≤5deg
    GPS ModuleGPS chip set: SiRF Star III
    Frequency: L1, 1575.42 MHz
    Number of Channel: 20
    Reacquisition: 0.1 sec, average
    Hot boot: 2 sec., average
    Warm boot: 38 sec., average
    Cold boot: 44 sec., average
    Altitude limit: 18000 m
    Velocity limit: 515 m/s
    CurrentNot working Current 16mA
    working Current:60~150mA
    Current of opening infrared of Camera at night :100~200mA
    Charging current: Max<500mA
    Input I/O8 I/O input/output Port
    1 main power check
    1 port use to check the engine ( ACC check)
    1 port use to SOS
    1 analog Input port( Fuel sensor)
    1 Output port ( Car engine control )
    3 Extend ports ( Input/Output control by software)

    2. Speed Limiter Requirement

    Ethiopia Standard Speed Limiting Device Speed Limiter Real-time Online Tracking​


    1. The road speed limiting device shall be designed and constructed in such a way that it can be fitted in a place not easily accessible;
    2. The road speed limiting device shall have in built features that allow functionality checks and shall have special inspection devices for this purpose to facilitate the checking when the vehicle is not in motion;
    3. The actuation force of the controls should not have a detrimental effect on the driver's efficiency or impose fatigue on the driver;
    4. Speed limiter devices shall be so constructed that the vehicle may not be accelerated by the operation of the acceleration devices, such as the accelerator pedal, when the vehicle is running at its set speed;
    5. Speed limiter device shall remotely communicate through telecom infrastructure;
    6. Speed limiter device shall have geo-fence management feature.
    7. The input speed signal shall be obtained from global navigating system (GNS) or speedometer vehicle speed signal or a converted speed signal from vehicle gearbox or from other separately installed sensor as deemed appropriate

    Ethiopia Standard Speed Limiting Device Speed Limiter Real-time Online Tracking​

    1. The speed limiter devices shall be of industrial grade and designed for automotive application ;
    2. All components necessary for full function of the speed limiter or the Speed limiter device shall be energized whenever the vehicle is being driven ;
    3. The device should provide functional check facility by which the set speed and functioning can be checked by the field and other concerned authorities;
    4. The speed limiter device system shall be equipped with a system which shall accept an external device for testing the speed limiter and verifying its functionality.

    3 Application Field:

    1. For School Bus ;
    2. For tour bus and passenger car management ;
    3. For logistics vehicle monitoring and management ;
    4. For tank truck monitoring and management.
    5. For limit the speed of vehicles

    200mA Electronic Engine Governor Speed Limiting Device Real Time Online Tracking200mA Electronic Engine Governor Speed Limiting Device Real Time Online Tracking
