Fuel Level Sensor/Oil Measure Sensor For Trucks/Oil Car With GPS
Connector Fuel Level
CLS2 Capacitor motor oil level sensor combined capacitor sensor and
liquid level sensor.The product not only contain the features of
high precision measurement and maintenance-free, at the same time
it doesn't influenced by temperature and medium.It can be
automatically measuring error caused by different temperature or
medium for precise compensation,achieving the purpose of accurate
measurement.
Technical features:
| Examination area: | 100~1000mm |
| Resolution ratio: | 0.10% |
| Measuring accuracy: | 0.10% |
| The maximal error of measure: | 1mm |
| Heat-resistant: | -40~150 |
| Diameter: | Φ18mm |
| Output signal: | 4~20mA, 0~5V, RS485, RS232, CAN bus |
| Voltage supply: | DC7~42V |
| Rated supply: | 0.1W |
| Fixed type: | Screw installation M20X1.5 OR Flange mounting |
| Pressure range: | -0.1MPa ~ 0.1 Mpa |
| Ambient temperature: | -40~85℃ |
Fuel Level Sensor/Oil Measure Sensor For Trucks/Oil Car With GPS
Connector
The entire sensor machine doesn't contain any elasticity or moving
parts.Impact resistance, maintenance-free, long service life, easy
installation,can be installed in various occasions.Accurate measure
for gasoline, diesel oil, hydraulic oil level and other
various weak corrosive liquid level .
Instruction
definition of the output line
Interface output line use 6 core cable, connecting definition:
0~5V output [CLS2A]:
Black line connect ground wire Red line connect positive power
White line 0~5V voltage signal output,connect voltage signal wire
Yellow line empty fuel tank use only
Green line full fuel tank use only
| RS232 | output [CLS2C] |
| Black line | connect ground wire |
| Red line | connect positive power |
| White line | RXD input, connect car RS232 TXD |
| Blue line | TXD output, connect car RS232 RXD |
| Yellow line | empty fuel tank use only |
| Green line | full fuel tank use only |
Fuel Level Sensor/Oil Measure Sensor For Trucks/Oil Car With GPS
Connector
Interface output line use 6 core cable, connecting definition:
0~5V output [CLS2A]:
Black line connect ground wire Red line connect positive power
White line 0~5V voltage signal output,connect voltage signal wire
Yellow line empty fuel tank use only
Green line full fuel tank use only
RS232 output [CLS2C]:
Black line connect ground wire Red line connect positive power
White line RXD input, connect car RS232 TXD Blue line TXD output,
connect car RS232 RXD Yellow line empty fuel tank use only
Green line full fuel tank use only
RS485output mode(CLS2D) Black line connect to CND red line connect
to VDD white line connect to RS485 A blue line connect to RS485 B
yellow line marking for empty fuel tank green line marking for full
fuel tank
Fuel Level Sensor/Oil Measure Sensor For Trucks/Oil Car With GPS
Connector
FAQ:
Do you have one GPS Tracker device that supports the fuel sensor?
Yes, all professional types of GPS trackers including V2E have the
support of this type of fuel sensors.
How can I buy it?
We accept T/T, Western Union, and Paypal after payment cleared.
then we will send goods to you.
What is your WhatsApp?
My WhatsApp is +8618673367060
