Lock GPS Tracking System Large Capacity Battery For Truck FB500 / JT701

Lock GPS Tracker For Container Tracking And Truck FB500 Same As JT701

Basic Info

Model NO.: FB500 /CA-P10

Network: 2g/3G

Port Number: Multichannel

Model: Integration Type

Screen Size: No Screen

Carrier Frequency: Dual-Frequency

Chip: Sirf

Trademark: JOINTECH

Transport Package: Carton / Plywood Box

Specification: 195mm x 114mm x 37mm

Origin: China

HS Code: 9032899090

Product Description

FB500 is an intelligent GPS Electronic lock, which combines GPS tracker remote management function and Electronic Lock function.
It is used mostly in customs goods supervision, Logistics goods transport, valued asset live monitoring, etc.
Lock GPS Tracker For Container Tracking And Truck FB500 Same As JT701

1. Smart tracking solutions for a wide range of applications
• Dry van
• Fixed assets
• Fracking operations
• Dry containers
• Trucking (TL)
• Other unpowered assets

2. Unique Features:
1. Intelligent Power Management
1) 15000mAh built-in battery:
lasts 7 ~ 30 days in real time monitoring mode.
lasts for ONE year if 2 position report / day
2). Smart working mode:
Built-in with 3-axis accelerometer
Upload position/status in different interval at moving and parking mode
The device will fall asleep if no motion detected for preset time, and be activated as soon as the motion detected.

3. Working Principle:
1). Load the goods, Authorize the ID cards, Swipe the card and lock the door with JT701
2). On the road: JT701 will upload the position to the server, you can monitor it in computer or mobile in real time
3). Desitination: Swipe the card to unlock JT701 (or unlock with password via SMS, unlock with command via software)
4). Reports: Who, When, Where unlocked, trace, can be checked at any time
5). Alarms: Low battery alarm, Sting cut alarm, card swiping, unlocking, wrong password SMS, vibration, geofence
Container Security Cable Seal Lock with GPS Tracker
Lock GPS Tracker For Container Tracking And Truck FB500 Same As JT701

4. Parameters:

Item	Note
Size	195mm x 114mm x 37mm
Weight	700g( Include main unit, antenna, battery, shell)
Material	Engineer plastic
GPS Module	Ublox MAX-7Q
GSM module	Quectel M35
Working temperature	-20°C -- +60°C
Store temperature	-40°C -- +80°C
Humidity	5%-99%
Standard battery	Rechargeable battery 15000mAh
Average working current	<90 mA
Average current stand by	<100uA
Waterproof standard	IP67
Transmission mode	Support TCP(GPRS) or SMS(message)

Applications:

Highlight of product:

1).Small size ,built-in GPS and GSM ANT;
2).Person,pet tracking ,Portable and waterproof PIX-6;

3). Support Phone Android and Apple APP tracking;
4). Read the position information and the remaining power battery by B / S and APP phone ;
5). Support SMS parameter settings and query functions;
6). Support station accessibility, low-power mode;
7). Customize the appearance of mold ;
8).Easy to install,Waterproof, Sleeping power-save mode .

Applications :

1).Track Private cars/Vehicle rental / Equipment outside etc;
2).Protect child / the elderly/ the disabled / pet /property etc;
3).Provide peace-of-mind for businessmen;
4).Manage field staff, 5.Track criminal secretly;
6).Manage the person bailed .

1. Car Rental / Fleet management and so on.

2. Container/cargo/asset tracking

Gurantee:

1. All of our product is free to use the Tracking platform server for first year.

2. All of our products there is a 2 year quanlity assurance.

Q:How could i get samples?
A:If you need to order sample for checking-up,we would like to ask you to pay for the samples and courier freight.We send the samples to you only after receipt of your payment.if you have an courier account,you can send your courier to collect samples from our company or send us the samples charge together with the courier cost.
Q:How much the Courier freight will be for the samples?
A:Courier freight depends on the quantity,weight and carton size and your area.
Q:How can i get your price list?
A:Please leave your contact way Such as Email/MSN/Skype/Tradmanager to us.we will contact to you and pass our quotation sheet to you.
Q:Can we have our logo or company name to be printed on your products or the package?
A:Yes,you can.Logo or imprints can be printed on our products by silk screen printing. The minimum quantitiy for silk screen printing is 100pcs per logo.You can send us the artwork by email.
Q:Can you arrange the transportation for us?
A:Yes,We can arrange transportation by sea or by air.
Q:What's your usual payment term for orders?
A:We accept terms of T/T / Westunion /Paypal /LC.
Q:what's the warranty of your products?
A:one year.
