Motorcycle GPS Tracker Remote Cut off Engine Petrol Free Tracking
Platform Geo fence
Device wire
1 Red line power supply
2 Black wire connected to the negative electrode
3 Orange line connected to ACC
4 Yellow line connect with relay control line.
Quick setting:
1, Insert a 2G GSM simcard ( or 3G 4G simcard if it support 2G GSM
Network)
2, Setup APN.
3, Setup IP and port (if don’t use our Tracking platform)
4, Setup Admin number to manage the tracking unit.
5, Setup alarm settings as per you need.
Knowing the important command:
1, G1234, To inquiry the position at anywhere and anytime.
2, CXZT, to know the device information.
3, CQ, to restart the device, when it not working.
Performance Parameters:
Content | Specs. |
| Name | Motorcycle GPS Tracker |
Network | 2G GSM GPRS |
Band | 850/900/1800/1900Mhz |
GPS chip | UBLOX |
GPS sensitivity | -159dBm |
GPS accuracy | 10m |
Time To First Fix | Cold status 38s Warm status 15s Hot status 1s |
voltage input | 9－100V input
|
Battery | Build-in 3.7V 140mAh Li-ion battery |
Storage Temp. | -40°C to +85°C |
Operation Temp. | -20°C to +55°C |
Humidity | 5%--95% non-condensing |
| Size | 7.6cm x 2.6cm x 1.3cm |
| Weight | 0.067kg ( Battery and Power cord Included ) |
| Waterproof | IP67 |
Function
| 1 Positioning and Tracking: Through the on-line Positioning Platform or the cell phone to
locates at times, and get the working status. You can choose the
positioning platform by yourself. |
| 2.Cutting off power and alarm. |
| 3 Remote controlling oil and circuit: you can control the oil and circuit via the unit by SMS in anywhere
and anytime. |
| 4 ACC checking; |
| 5. Overspeed Alert: Send SMS to the unit to start the movement alert function. When
the vehicle is overspeed, the unit will send the overspeed alert to
all authorized numbers. |
| 6. Movement Alert: Send SMS to the unit to start the movement alert function. When
the vehicle is moving, the unit will send the movement alert to all
authorized numbers |
| 7 Geo-fence: Set up a geo-fence for the unit to restrict its movements within
a district. The unit will send the message to all authorized
numbers when it breaches the district. |
| 8. Auto Track: You can set up auto track by SMS or on-line positioning platform. |
| 9.Mileage statistics; |
| 10. Three ways tracking: SMS inquiry position, Phone app, PC
tracking. |
| 11. Modify the IP and Port of Communication Protocol for different
on-line positioning platform. |
