Real Time Mini GPS Tracking Chip Mini GPS Receiver Tracker/Car GPS
Locator With Remote Control
C003-01-4G model is a 4G real-time positioning terminal device that
can realize functions such as electronic fences, remote tracking,
and
one-key car lock.
The C003-01-4G model is small in size and easy to install and fix.
The product has a built-in 200mAh battery.
Real Time Mini GPS Tracking Chip Mini GPS Receiver Tracker/Car GPS
Locator With Remote Control
Project Note
| Communications | Support TCP/IP |
| support TCP ,SMS , |
| Location | Real-time monitoring |
| Report by configuration interval |
| Support corner reporting (during wake-up call) |
| General | Support vibration detection trigger |
| Support rollover warning (optional); |
| gsensor for mandatory closure |
Real Time Mini GPS Tracking Chip Mini GPS Receiver Tracker/Car GPS
Locator With Remote Control
Specifications
| Project | Specifications |
| Size | 90*40*15mm |
| Working voltage | 9-80V |
| Working temperature | -20℃ -- 70℃ |
| Working humidity | 20%-80% non-condensed water |
| Battery capacity | 200 mah |
| Working current | 22ma(12VDC),12MA(24VDC) |
| Standby time | More than 180 days (2 records per day) |
| Net weight | 0.05kg |
| Communications frequency | Please refer to the distribution table |
| GPS sensitivity | 159 bdm |
| Positioning accuracy | <10 m |
| Cold start | <38 s (average) |
| Hot start | <2 s (average) |
Proposed hidden place:
(1) Below the windshield inside the decorative panel;
(2) Car meter (surface of non-metallic materials) around the
shelter;
(3) Rear windshield below the decorative panel;
(4) Inside car door or pillar;
(5) Within the dashboard or under back seat hidden
Note:
(1) If below the windshield there is metal insulation or heating
layer will reduce the GPS signal reception, causing the GPS
malfunction, please change the installation position;
(2) Some models are built-in 3D sensor, and it needs to detect
acceleration, deceleration and rollover, equipment must be
installed according to the mounting direction front and rear
direction of the vehicle can not be mounted transversely.
Real Time Mini GPS Tracking Chip Mini GPS Receiver Tracker/Car GPS
Locator With Remote Control
Frequently asked questions
Q: Can the customer`s location monitoring systerm be used?
A: Of course.we will send you the communication protocol,and you
can modify the communication protocol according to our protocol.
Q: Can the appearance be defined? Can product functions be
customized?
A: Of course.The appearance and functions can be customized.
Our services:
1.Reply Time: All inquiries will be answered within 24 hours.
2. Payment Times: We accept payment by T/T or western Union or
paypal.
3. Shipment Times: All orders can be shipped out within 1-3 working
days normally. Once the order is shipped out, we will send an email
to you include the track number and the package photos.
4. MOQ Limitation: No MOQ limit, 1 pc for sample checking is
available.
