4G GPS Tracker 3000mah Rechargeable Magnetic Mini Device With Free
App Platform
Product function
Real Time LBS position vehicle GPS Locator motorcycle waterproof
magnetic long battery alarm system tracking device gps tracker
1. Long Standby Time: It has built-in 3.7V 3000mAh Li-ion battery,
can standby up to 10 days(Maximum standby time in sleep model).
2. Powerful Magnetic: It has built-in magnets,with super strong
powerful magnetic,can be very easily installed.
3. Overspeed Alarm: This alarm works only under continuous
positioning mode.When the unit speed is exceed the speed you
presetted, it will send message "speed alarm!" to the admin number
every 5 minutes.
4. Shake Alarm: After you did the shake alarm setting,please keep
the tracker being stationary for 5 minutes, then this function will
start working. It will send SMS "sensor alarm!" to the admin number
when the unit get shocked.
5. Sleep Mode:* Sleep by time mode: After did this setting, tracker
will only work for 5 minutes after being waked up, and back to
sleep mode, GPS will shut off and GSM will works in low consumption
mode. SMS, call will can wake up the tracker. * Sleep by shock
sensor mode: After did this setting, if no shock for 5 minutes, the
tracker will work under "sleep by shock" mode, GPS will shut off,
GSM will works in low consumption. Vibration, SMS, call will can
wake up the tracker.
6. History Route Playback: You can track the history route of the
device up to 6 months via both the web platform and APP.
7. Lifetime free WEB Tracking platform and Mobile APP Android/IOS
Tracking: no any yearly subscription
Parameters
| Items | Parameters |
| Frequency band | 4G LTE-TDD/FDD full band |
| LBS Positioning Accuracy | 100-500m |
| GSM Antenna | Built-in |
| GPS Positioning Accuracy | 5-10m, 2D RMS |
| GPS Antenna | Built-in |
| Working Voltage | 9VDC～100VDC |
| Working Current | <50mA |
| Operating Temperature | -20℃—70℃ |
| Humidity | 5%—95% |
| Size | 78*39*29mm |
| Simcard | Normal simcard |
| Battery | Rechargeable polymer battery 3000mAh |
Professional Platform and APP
About web tracking platform:
Free Web tracking software,no charge fee,login page: www.ytwl-gps.com
Please choose English and log in your account registered in APP.
About ANDROID/IOS APP Tracking:
APP Name: gps speed limiter. Search"GPS SPEED LIMITER" in the Apple App Store/Google Play Store to install the
applications on your cell phone. .Register and add account.
4G GPS Tracker 3000mah Rechargeable Magnetic Mini Device With Free
App Platform
FAQ
Q1. Can I ask for samples before placing an order?
A1: Yes, we welcome sample order to test and check quality.Mixed
samples are acceptable.
Q2. If your GPS devices can work with my own server?
A2: Yes, we will offer you the engineering code to help you
transfering the communication protocol, so that our device can work
with your own server harmoniously.
Q3. How can I work with you for my OEM/ODM orders?
A3: 1>For OEM orders on the models we alraedy have, we accept
30% initial payment after the sample test, the balance must be
cleared before the shipment;
2>For design new model for your own, we need the full payment
for the sample R&D, normally, the sample will be come out after
45 days, after that we can negitiate the details for the mass
production.
Q4. Can your print my own logo?
A4: Yes, please send us your logo pattern, we will offer sample
with your logo before mass production.
