Lightweight Car Gps Tracker Support Acc And Shock Sensor , Gps
Locator For Car
Description:
5. LED Indicator
- Yellow LED-GSM(Power / state)
| LED state | Meaning |
| Always light | GPRS working normally |
| Flashing | GSM initialization |
| Always dark | NO GSM signal or sleep model |
- Blue LED-GPS(Power / state)
| LED state | Meaning |
| Always light | GPS working normally |
| Flashing | GPS initialization |
| Always dark | NO GPS signal or sleep model |
- GSM 850/900/1800/1900MHZ Full Band;
- Car GPS Tracker built-in switching power supply, exceed wide
voltage input range: 9-80 VDC;
- Waterproof GPS Tracker GPS continuous GPS positioning, GPRS report
regularly;
- Waterproof GPS Tracker Support SMS message to check the location
info;
- It’ll sleep automatically when it’s still and will be awakened by
moving, therefore, it can save power a lot.
- It supports geofencing set by the webpage GPS tracking
platform/smart phone APP/messages, once it’s out of fence, a warning will be sent to the
monitor phone number.
- Built-in vibration sensor, realization vehicle anti-theft
intelligently;
- ACC the ignition signal detection,vehicle status prompted;
- Built-in backup battery, realize the illegal cut the line alarm;
- Automatic failure recovery;
- Waterproof design, Easy to install and setup with only 3pc Line.
Detail Pictures:
- IP67 dust and water proof
- Built-in Li-ion battery, Power disconnection alarm function
- Watch dog function,reboot automatically after breakdown
Applications :
- Motorcycles Anti-theft
- Vehicle rental / Fleet management Solution.
Gurantee:
1. All of our product is free to use the Tracking service server in
24 hours each day
2. All of our product there is a 2 year quanlity assurance.
3. Sample fee will not be returned.
Product Configuration:
1. Standard configuration
1 Power Line
2 CA-V5W Device 1pc
3 User manual 1pc
9. Installation
9.1 Please find the professional and technical personnel for
installation.
9.2 Pay attention to the following items:
9.2.1 In order to avoid thieves damage, please select a hidden
place to install.
9.2.2 Not place with other emission source, such as reverse sensor,
car alarm, and other vehicle communication device.
9.2.3 Use cable tie to fixed or use a wide strong double-sided tape
to stick;
9.2.4 Device with built-in GSM antenna and GPS antenna, so make
sure the front of device face to the air, and without metal cover
above the device.
Note:
If there is metal insulation layer or heat layer paste with the
windshield, it will cause GPS signal weak and make device work
abnormal. So please replace the device installation location.
10. Recommended installation location
10.1 The decorating plate below the front windshield of the car;
10.2 Around the car dashboard (skin for non-metallic material);
10.3 The decorating plate below the back windshield of the car;
10.4 In the car door or in the column;
10.5 In the dashboard of motorcycle or electric bike, or below the
back seat.
11. Trouble shooting
11.1 After the first installation, if it is not online on the
platform, please check the device installation:
11.1.1 Check the main power wire
11.1.2 Check the SIM card
11.1.3 Check the power switch, switch is on the edge of the back
cover.
11.1.4 Check the state of LED lights
11.1.5 Check the GPS location, if not, please go outside to locate
for the first time.
11.2 It is off-line on the platform
First check the indicator light, and if no condition to check LED,
please check the SIM card state, as follow:
11.2.1 Dial the SIM number in the device, check the dial tone.
11.2.2 Check the car is in the basement without gsm signal
11.2.3 Check the dropped area, confirm individual drops or all
drop, so can determine whether network for operators
11.2.4 Check the SIM card arrearage
11.2.5 GPRS service is cancelled (at the end of the last day of
offline)
11.2.6 Check the parameters settings, is the interval of upload
correct?
11.3 If the GPS function is activated, but can not locate for a
long time, please check the device installation location.
11.4 If specific number phone receive the SMS about power off
alarm, determine whether illegal cutting line, otherwise please
check whether the fuse on the power wire.
