nstructions:
GPS&GSM Quad-band Real-Time Tracking & location And history
Track playback ( use)
Wide input voltage range: DC 9-24V
Build-In vibration sensor, Smart Anti-theft
External Loudspeaker, used In Phone calls or Alarms case
Movement Alar
External Microphone realize Remote Monitoring And intercom, used In
Voice Monitoring case
External SOS Button And Alarm And speakers
External Relay realize Remote Enigine power & oil off
Alarm function: Speeding, Vibration, Geo-fence And illegal shift
Alarm By Real-Time SMS
Built-In Battery (support overtime standby & Alarm when Electricity
Cutting or lower power)
Acc Ignition Detection, Vehicle status notification
Firmware Auto recovery function
For IOS, Android APP Software In set, also support WeChat Tracking
on line
23. Set ACC open and close send SMS notify
You can set the SMS notify of when ACC on and off. The format of
set is “accnotify + 1 or 0”. For example “accnotify 1” stand for when ACC on and off send SMS
to authorized numbers. “accnotify 0” stand for close send SMS
notify. In order to use this function, you must set authorized
numbers.
24. Get GPS Info with Google Format
You can get latitude and longitude with Google website format. So
you can open map directly by mobile. The format of SMS is “google”. After you send SMS, tracker will reply GPS info with google
website format.
25. Set call reply SMS format
You can set reply SMS format after you call tracker. The format of
SMS is “geosms + value”. The SMS of “geosms 1” set reply SMS format as “position”. The
SMS of “geosms 2” set reply SMS format as “google”.
◆Installation diagram of The Tracker
◆GPS Vehicle Tracker Installation
GPS tracker should be installed by technical professional of local
service centre. Without permission, the user cann’t repair and move
the tracker randomly. If users do, any unfortunated damage should
be compensated by himself.
Installation steps (caution: the following installation should
under no power, otherwise will be dangerous)
1.Power supply line: The red wire connects 12V“+”;Black wire connects to 12V“-”
2. Wire for cutting off oil of the tracker
Yellow wire connects the relay pin 86; 85 pin connect to 12 V DC ,
87a pin and 30 pin in series power supply circuits. Caution: Wrong
connection of yellow wire will damage the tracker.
3. Wire for cutting off circuit of the tracker
White wire connects relay pin 86; 85 pin to 12 V DC, 87a pin and 30
pin are in series power supply circuits. Caution: Wrong connection
of yellow wire will damage the tracker.
4. Emergency triggering alarm
The blue wire connects the positive of the alarm button, and the
black wire connects the negative of the alarm button.
◆Application
- Vehicle Rental/Special Tracking System
- Finance and Insurance Business Tracking System
- Car Commanding and Dispatching System
- Heavy Construction Vehicles Tracking Device
- Shipping Cargoes Tracking
FAQ:
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown
cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your
authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the
photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your
advance payment. The specific delivery time depends
on the items and the quantity of your order
